Western© and Fisher© Snow Plow Hydraulic Pump Motor// 12V// CW// Slotted Shaft
Applications: Western© and Fisher© Uni-Mount plows.
Part #: 51050
This is motor with scalloped bottom, (the other newer style Fisher motor has an open flange @ bottom)
Rotation: CW
Field Housing O.D.: 4.492 in.
Overall Length: 8.268 in.
Shaft Outside Diameter: .626 in.
Shaft Style: Slotted
Aftermarket
Terminal 1 Size: 5/16 - 24
Terminal 2 Size: 5/16 - 24
Housing Finish: Drive end is cast aluminum with a red painted field case.
Weight: 17.3 lbs.
Notes: Includes mounting plate with two 1/2 - inch holes. Insulated ground motor.
Cross References:
Prestolite©: 46-2473, 46-2584, 46-3618, 46-3938, MKW-4009, MUE-6103, MUE-6103S, MUE-6111, MUE-6111S, MUE-6206, MUE-6206AS, MUE-7001
Western Snow Plow©: 50133, 54133, 56058, 56062, 56133, 56398, 56410, 58058, 58082
Buyers©: 13036325, 1306415
